Leuze IS 112 MM/2NO-4E0
Non-returnable
Price:
₹430.00
Customize
1. Metal housing (M12): Durable cylindrical design. 2. Flush mounting: Suitable for embedded installations. 3. Sensing range: 4 mm Standard detection distance. 4. 2 NO outputs (NPN): Dual normally open switching. 5. LED indicator: Shows switching status. 6. 3-wire DC connection: Simplified wiring. 7. High switching frequency: 3,000 Hz, Fast response. 8. IP67 protection: Dustproof and waterproof. 9. PVC cable (2 m): Pre-wired for easy installation. 10. Operating temp: -25 to +70 °C, Wide temperature range.
1. Series: 112 2. Sensing Distance: 4 mm 3. Supply Voltage: 10 to 30 V DC 4. Switching Output: Transistor, NPN 5. Switching Principle: Normally Open (NO) 6. Switching Current (Max.): 200 mA 7. Residual Current (Max.): 0.01 mA 8. Voltage Drop: ≤ 2 V 9. Switching Frequency (Max.): 3,000 Hz 10. Connection Type: PVC Cable, 2,000 mm Length 11. Number of Conductors: 3-wire 12. Design: Cylindrical 13. Installation Type: Embedded 14. Housing Material: Metal 15. Sensing Face Material: Plastic, Polybutylene (PBT) 16. Standard Measuring Plate: 12 x 12 mm², Fe360 17. Ambient Temperature Range: -25 to 70 °C 18. Degree of Protection: IP67 19. LED Indicator: Yes
