Leuze LE328/4P-M12 - Throughbeam photoelectric sensor receiver
Price:
₹2,740.00
Out of stock
Leuze LE328/4P-M12 - Throughbeam photoelectric sensor receiver
Customize
1. Throughbeam Receiver: Requires a matching transmitter (e.g., LT328). 2. Long Detection Range: Up to 15 meters, ensuring reliable performance in wide spaces. 3. Compact M18 Design: Ideal for installations in tight or standardized cylindrical mounting points. 4. Dual Switching Outputs: Light switching (when beam is uninterrupted). Dark switching (when beam is broken). 5. Fast Response Time: 1 ms, suitable for high-speed automation tasks. 6. High Switching Frequency: 500 Hz, enabling detection of fast-moving objects.
1. Supply Voltage: 10 to 30 V DC 2. Current Consumption: ≤ 15 mA 3. Max Output Current: 100 mA per output 4. Protection: Short-circuit, reverse polarity protection 5. Connector Type: M12, 4-pin male 6. Standard Pin Assignment (for PNP sensors) 7. Switching Outputs: 2x PNP (sourcing) – for light switching and dark switching 8. Switching Frequency: 500 Hz 9. Response Time: 1 ms 10. Housing Size: M18 x 46 mm 11. Material: ABS body with stainless steel thread 12. Protection Rating: IP67 (dust-tight, water-resistant) 13. Temperature Range: -40°C to +60°C
